Subwoofer Driver | 700 W Peak Power | 250 mm (10 in.) | 4 ohm
All the depth of TH 10 BASSO, completely flush-mounted under the teak or into a hatch. Identical driver and identical control, with nothing visible on the surface: only bass that shapes the whole experience from below. Available in white and black. Technical Specs
Nominal diameter 250 mm (10 in)
Impedance 4 Ohm
Power Handling - Peak 700 W
Power Handling - Continuous 350 W
Sensitivity 89.5 dB
Frequency Response 30-500 Hz
Voice Coil Ø 60.5 mm
Chassis Material PLASTIC
Magnet Material HIGH DENSITY FLUX FERRITE
Magnet size D x d x h 150 x 70 x 36 mm
Voice Coil Material CCAW
Former Material FIBER GLASS
Cone Material POLYPROPYLENE WITH UV INHIBITORS
Surround Material RUBBER
Xmax 20.6 mm (0.81 in)
Xmech 15.1 mm (0.59 in)
Voice Coil Winding Height 35.2 mm (1.39 in)
Gap Height 10 mm (0.39 in)
Recommended Enclosure 80 l (2.825 ft) Electric-acoustic Specs
D 327 cm² (50.685 in²)
Re 3 Ohm
Fs 50 Hz
Le 0.32 mH
Vas 20.3 l (0.717 ft)
Mms 77.5 g (2.734 oz)
Cms 0.13 mm/N
BL 8.6 T•m
Qts 0.864
Qes 0.956
Qms 8.9 General
Weight 7.8 kg Dimensions
Dimension A 319.5 mm (12.58 in)
Dimension B 267 mm (10.51 in)
Dimension C 189 mm (7.44 in)
Dimension D 174 mm (6.85 in)
Dimension E 15 mm (0.59 in)
Dimension U 291 mm (11.46 in)
Dimension V 5.5 mm (0.22 in)
