Subwoofer Driver | 2000 W Peak Power | 300 mm (12 in.) | 4 ohm
A larger cone for maximum low-frequency authority. TH 12 BASSO answers the vessels and the moments where music has to be felt as much as heard: 1000 W RMS and a neodymium motor deliver bass that fills an open deck without ever losing its shape, with the same marine construction and the same relentless control as the rest of the collection. Technical Specs
Nominal diameter 300 mm (12 in)
Impedance 4 Ohm
Power Handling - Peak 2000 W
Power Handling - Continuous 1000 W
Sensitivity 90 dB
Frequency Response 25-350 Hz
Voice Coil Ø 99 mm
Chassis Material PLASTIC
Magnet Material NEODYMIUM
Magnet size D x d x h 97 x 31 x14 mm
Voice Coil Material CCAW
Former Material GLASS FIBER
Cone Material POLYPROPYLENE WITH UV INHIBITORS
Surround Material RUBBER
Xmax 20.8 mm (0.82 in)
Xmech 28.3 mm (1.11 in)
Voice Coil Winding Height 48 mm (1.89 in)
Gap Height 12.5 mm (0.49 in) Electric-acoustic Specs
D 516 cm² (79.98 in²)
Re 3 Ohm
Fs 50 Hz
Le 0.7 mH
Vas 23.3 l (0.823 ft)
Mms 166 g (5.855 oz)
Cms 0.06 mm/N
BL 11.6 T•m
Qts 1
Qes 1.17
Qms 7.6 General
Weight 12.2 kg Dimensions
Dimension A 356 mm (14.02 in)
Dimension B 306 mm (12.05 in)
Dimension C 239.4 mm (9.43 in)
Dimension D 199.9 mm (7.87 in)
Dimension E 39.5 mm (1.56 in)
Dimension U 325 mm (12.8 in)
Dimension V 5.5 mm (0.22 in)
