The force behind every BASSO. TH MONO is a dedicated monoblock built to drive marine subwoofers with the headroom low frequencies demand on open water: 750 W at 4 ohm, 1300 W at 2 ohm and 2200 W at 1 ohm, paired with the processing handled upstream. Available in 12 V and 24 V architecture. Amplifier Tech Data
Channels 1
Class ADC (Advanced D-Class)
Hi Level Input No
Low Level Input Yes
Digital Input No
Operating power supply voltage 11 ÷ 15 VDC
Idling current 1.8 A
Remote OUT 6.5 ÷15 VDC (150 mA)
Remote IN 4 ÷15 VDC (1 mA) Amplifier Stage
Bandwidth A 10 Hz ÷ 500 Hz
Total Power RMS 2200 W
Minimum load impedance 1 ohms
Output Power (RMS) @14.4 VDC, 1% THD 750W x 1 (4ohms)
1300W x 1 (2ohms)
2200W x 1 (1ohms)
Adjustable Crossover No Inputs
Input Type Pre-In General Requirements
Operating temperature range -15°C ÷ 55°C (5 °F to 131 °F) Dimensions
Dimension A 360 mm
Dimension B 320 mm
Dimension C 203 mm
Dimension D 163 mm
Dimension E 55 mm (2.17 in)
Dimension C1 239 mm (9.4094 in)
